BASIC INFO
| Electrical Specification Model:RT-HC0202-638-4310F-155 | |||
| Frequecny Range | 600-3800MHz 600-4000MHz |
||
| Coupling | 3±0.65dB | ||
| Insertion Loss | 0.65dB |
||
| Isolation | 23dB |
||
| VSWR | 1.25 |
||
| PIM3 | -155dBc@2*43dBm | ||
| Power | 200W |
||
| Impedance | 50 ohm |
||
| Connector | 4.3-10 Female/N Female |
||
| Temperature | -30℃ - +70℃ |
||
| Application | Outdoor | ||
| Net Weight | 0.60Kg | ||
